Full Inverter VELTERRA Swimming Pool Heat Pump (Heating & Cooling) – R32
VELTERRA-030TD1 uses an air-source heat pump to transfer energy from ambient air to pool water via a heat exchanger, delivering a stable pool temperature and improved energy efficiency.
It offers multiple operating modes—ECO, Heating, Powerful Heating, and Cooling—so you can prioritize energy saving or fast warm-up based on your pool needs.
The unit is specified to operate at ambient temperatures from -15°C to 43°C, with water operating limits including an 8°C minimum inlet water temperature and a 40°C maximum outlet water temperature.
Key Features of VELTERRA Swimming Pool Heat Pump
-
Full inverter performance with precise EEV refrigerant control.
-
Heating & cooling modes: ECO / Heating / Powerful Heating / Cooling.
-
Built-in WiFi + wired controller.
-
Titanium heat exchanger for pool water applications.
-
R32 refrigerant.
-
ABS casing and IPX4 protection.
-
Automatic defrosting via 4-way valve.
Technical Specifications
-
Heating capacity (Air 26°C / RH 80% / Water 26→28°C): 28 kW (listed as 28±6.8 kW).
-
Heating capacity (Air 15°C / RH 70% / Water 26→28°C): 23 kW (listed as 23±5.5 kW).
-
Max power input: 4.45 kW.
-
Max current: 20.4 A.
-
Power supply: 220–240V, 1Ph, 50Hz.
-
Water flow volume: 9 m³/h.
-
Water connections: DN50 (inlet/outlet).
-
Working ambient range: -15°C to 43°C.
-
Noise level: 47–58 dB(A) at 1 m, and 27–38 dB(A) at 10 m (depending on condition).
-
Net/Gross weight: 88 / 99 kg.
-
Net dimensions: 1084 × 399 × 737 mm.
Contact us on WhatsApp or call us at 01146787877
FAQ about VELTERRA Swimming Pool Heat Pump
1. How does VELTERRA Swimming Pool Heat Pump Full Inverter technology save electricity?
Instead of running at 100% capacity and shutting off, the Full Inverter compressor adjusts its speed to maintain a steady temperature. This prevents energy spikes and reduces electricity consumption by up to 80% compared to traditional heaters.
2. Can this unit both heat and cool my pool?
Yes. The VELTERRA-030TD1 features a reversible cycle. It provides Heating for winter comfort and cooling to refresh your pool during extreme summer heat, maintaining water between 8 °C and 40 °C.
3. Is it safe for saltwater or chlorine pools?
Absolutely. It is equipped with a Titanium Heat Exchanger, which is 100% resistant to corrosion from salt, chlorine, and other pool chemicals, ensuring a long lifespan in any pool environment.
4. Can I control the VELTERRA Swimming Pool Heat Pump remotely?
Yes. With built-in WiFi, you can monitor water temperature, switch modes (like ECO or Powerful), and turn the unit on/off via your smartphone from anywhere in the world.
